1000W IGBT heat sink solution


Customized 1000W IGBT heat sink case sharing

-Fin space :3mm
The ambient temperature is 35℃;
-LED thermal power 1000W;

YT thermal 1000w IGBT heat sink

-Between the heat source and the heat sink is a thermal paste with a thickness of 0.15mm and a thermal conductivity of 3W/mk;

IGBT heat sink design
custom 1000w IGBT heat sink
-Forced convection air cooling is used;
-Since there is no detailed information such as the thermal resistance of the heat source, the temperature of the junction of the heat source cannot be checked, you can refer to the radiator substrate temperature.
