35W liquid cold plate Inverter thermal solution


Customized 35W cold plate case sharing

Coolant flow: 2L/min
Coolant temperature: 55 ℃
60% ethylene glycol solution
Ambient temperature: 55 ℃
Single chip power consumption: 35W

Fluid Domain Pressure and Temperature Distribution

custom 35w liquid cold plate
35w liquid cold plate for inverter
custom liquid cold plate for inverter

Since the heat source has no detailed information of the internal chip, there is no heat source temperature, you can refer to the temperature at the cold plate corresponding to the heat source; Under the existing model parameter input, you can see: The maximum temperature of the water cooling plate is 80.85℃.
